Remote Control
Page 27
restored from the non-volatile RAM at power-on. The factory default
is 1 (clear all the enable registers).
*RST RESET
Type: Internal command
Function: IEEE 488.2 level 3 reset. This command will set the length of the
DLS 50 to 0 kft (or 0 km), and cancel any pending *OPC operation. It
will not affect the output buffer or other system settings of the unit.
Note that this is NOT equivalent to the power-up reset and the IEEE
488 "Device Clear".
*SRE <NRF> SERVICE REQUEST ENABLE
Type: Status command
Function: Sets the Service Request Enable Register (SRER). An integer value
indicates which service is enabled, with the following bit map:
Bit: 76543210
Not used, should always be 0
1 = Enable Message Available bit (MAV)
1 = Enable Event Status bit (ESB)
don’t care, MSS is always enabled
not used, should always be 0
Bit 7 to 0 have a respective value of 128, 64, 32, 16, 8, 4, 2 and 1. For
example if bit 4 and 5 are set then the integer value is 48 (16+32).
Note that if both MAV and ESB are disabled, then the bits MSS and
RQS and the line SRQ are never going to be raised (see section 4.5.1
for more details).
On power-on, this register is cleared if the Power-on Status Clear bit is
1, or restored if the bit is 0 (see *PSC for more details).
