Getting Started
Page 10
The resolution of the cable length is 100 ft for units that use feet, and 50 m for units that
use metres.
The DLS 50 sets the cable length after 1 second of keyboard inactivity .
3.4 Configuring the DLS 50
Pressing both the Left and Right arrow keys at the same time gets into the unit setup
menus, where some of the operational characteristics of the unit can be changed.
The user can move among the different fields using the Left and Right arrows. The Up
and Down arrows will change the setting of the selected feature. On any of the setting
screens, pressing both Left and Right arrow keys at the same time returns to the main
screen.
1 – LCD Contrast : 7 [0…10]
More à
Fig. 3.5 LCD Contrast
To change the contrast of the display use the following steps:
• From the main screen, press both the left and right arrows simultaneously.
• Use the up and down arrows to select the desired contrast.
• Press the left and right arrows simultaneously to return to the main screen.
The contrast value is saved in non-volatile RAM, and will be restored on power up. The
default contrast is 7.
2 – IEEE 488 Address: 13 [0…30]
ß More More à
Fig. 3.6 IEEE 488 Address
