Getting Started
Page 11
To change the IEEE 488 address of the DLS 50 use the following steps:
• From the main screen, press both the left and right arrows simultaneously.
• Press the right arrow once to get to the IEEE 488 Address screen.
• Use the up and down arrows to select the desired address.
• Press the left and right arrows simultaneously to return to the main screen.
The address is saved in non-volatile RAM, and will be restored on power up. The
default is 13. See section 4.1.2 for more details.
3 – Serial: 9600 N81 Flow Ctrl:CTS
ß More More à
Fig. 3.7 RS-232 Interface
To change the serial interface baud rate, data format or flow control, use the following
steps:
• Press both the left and right arrows simultaneously
• Press the right arrow until you get to the RS-232 Serial interface protocol
screen
• Use the up and down arrows to select the desired baud rate.
• Press the right arrow key
• Use the up and down arrows to select the desired data format.
• Press the right arrow key
• Use the up and down arrows to select the desired flow control method.
• Press the left and right arrows simultaneously to return to the main screen.
The parameters are saved in non-volatile RAM, and will be restored on power up. The
defaults are 9600, N81 and CTS. See section 4.2 for more details.
4 – Restore Setting on Power up: Yes
ß More More à
Fig. 3.8 Restore on Power up
