Specifications
Page 41
Options:
(1) Rack mount kit
(2) Extended version
(3) Ziatech IEEE 488 interface card
(4) IEEE 488 shielded cable
7.1 ELECTRICAL
7.1.1 AC Power
Rated Input Voltage: 100-240VAC(±10%).
Rated Frequency: 50-60Hz.
Rated Power consumption: 30VA max.
Line Fuses: Type "T" 0.25A/250V SLOW BLOW (2 required,
5mm x 20mm).
7.2 ENVIRONMENTAL
Operating Temperature: +10°C to +40°C.
Storage Temperature: +10°C to +40°C.
Humidity: 90% (non-condensing) max.
7.3 MECHANICAL
Weight: 4.5Kg, 10 lbs
Dimensions: 42mm x 429mm x 366mm (H x W x D).
1¾" x 17" x 15"(1U height.)
7.4 OPERATING CONDITIONS
In order for the unit to operate correctly and safely, it must be adequately ventilated.
The DLS 50 contains ventilation holes for cooling. Do not install the equipment in any
location where the ventilation is blocked. For optimum performance, the equipment
must be operated in a location that provides at least ½" (10 mm) of clearance from the
