Specifications
Page 40
IEEE 488 Remote Control:
The unit can be controlled via an IEEE 488 interface. The unit supports the following
functions:
a) Listener
b) Talker
c) Local Lockout
d) Serial Poll
e) Selective Device Reset
f) Bus Reset
g) Primary Addressing from 0 to 30
RS-232 Remote Control:
The unit can be controlled via a RS-232 serial interface. The unit supports the following
functions:
Baud Rate: 300, 600, 1200, 2400, 4800, 9600, 19200, 38400
Data Format: E71, O71, E72, O72, N72, E81, O81, N81 and N82
Where:
E = even parity
O = odd parity
N = no parity
the second digit is the character size
the third digit is the number of stop bits
Flow Control: None, CTS, RTS/CTS, XOn/XOff, All
Connections:
2 (one per terminal) 8 way RJ-45 connectors at the front and back. Also two 2 pole
terminal strips and an extra set of RJ-45 connectors at the back. All connectors are in
parallel.
