Getting Started
Page 12
On power up, the DLS 50 can restore the length of the wireline that was used when the
power was turned off, or it can set the length to 0. To change the setting use the
following steps:
• From the main screen, press both the left and right arrows simultaneously.
• Press the right arrow until you get to the Restore Setting screen.
• Use the up and down arrows to select the desired setting.
• Press the left and right arrows simultaneously to return to the main screen.
The setting is saved in non-volatile RAM, and will be restored on power up. The default
is yes.
5 – Checksum: 1A2B3C Version:05 RAM:OK
ß More
Fig. 3.9 System Status
The last screen shows the checksum of the EPROM, the version of the firmware and the
non-volatile RAM state. No change can be done in that screen.
