Digital Monitoring Products, Inc. | 7800 Series Installation and Programming Guide 15
PROGRAM THE PANEL
To access the Programmer menu, reset the panel, press Keypad in the carousel menu,
enter 6653 (PROG), then press CMD.
After completing each of the following steps, press CMD to advance to the next option.
Refer to the panel programming guide as needed.
DEVICE SETUP
Advance to Device Setup, then press a select area to enter
the setup menu.
Device Number
Set the keypad address from 1-8 for XT30, XT50, and XR150
Series panels, or 1-16 for XR550 Series panels.
Device Name
Enter the a name for the device.
DEVICE SETUP
DEVICE SETUP
DEVICE NO: -
DEVICE SETUP
*UNUSED*
