TEST THE KEYPAD
Test the keypad to ensure keypad lighting, individual shortcut keys, and any programmed
zones work properly. Access the Keypad Diagnostics menu by pressing Options in the
carousel menu. Press the Installer Options or wrench icon and enter 3577 (INST) and
press CMD.
KEYPAD DIAGNOSTICS
Press the select area for KPD DIAG. The keypad lights all
display segments and illuminates red. The display then
changes to green. The keypad alternates between these two
states for up to two minutes. Press CMD at any time to begin
testing individual keys.
Zone Test
This option allows the keypads to display the current electrical
status of the four protection zones. The status is shown as
OPEN, SHRT, or OKAY. The zone test displays on the other
keypads, but is not operational.
Test the Credential Reader
This option tests the internal and external reader input from
proximity credentials. The display shows OKAY each time a
good proximity read is received.
KPD KPD
OPT DIAG STOP
Z1 OPEN Z2 OPEN
Z3 OPEN Z4 OPEN
INPUT WIEGAND
