7000 Series Installation and Programming Guide | Digital Monitoring Products 16
TEST THE KEYPAD
Test the keypad to ensure keypad lighting, individual shortcut keys, and any programmed zones work properly. To
begin testing, access the Installer Options menu. Hold down the back arrow and CMD keys at the same time until SET
BRIGHTNESS displays. Enter 3577 (INST) and press CMD.
Keypad Diagnostics
Press the select key under KPD DIAG. The keypad lights all display segments and
illuminates the keyboard in red. The display backlighting then changes to green/blue.
The keypad alternates between these two states for approximately two minutes. Press
CMD at any time to begin testing individual keys.
Test Individual Keys
The display changes to PRESS KEY TO TEST. This option tests each key on the
keyboard to ensure it is operating properly. Press and hold each key for two seconds.
The key number being held appears in the display. Verify the correct number displays
before testing the next key.
Zone Test (7070, 7073/A, 7170, 7173)
This option allows the keypads to display the current electrical status of the four
protection zones. The status is shown as OPEN, SHRT, or OKAY. The zone test
displays on the other keypads but is not operational.
Input Wiegand (7063/A, 7073/A, 7163, 7173)
This option tests the internal and external reader input from proximity credentials.
The display shows OKAY each time a good proximity read is received.
Exiting the Installer Options
When done, press CMD once to return to the Installer Options screen. Press the select key under STOP to exit the
Installer Options function.
KPD KPD
OPT DIAG STOP
PRESS KEY TO
TEST
Z1 OPEN Z2 OPEN
Z3 OPEN Z4 OPEN
INPUT WIEGAND
