7000 Series Installation and Programming Guide | Digital Monitoring Products 15
Additional Programming
Users can manually enter their user code into the keypad which then verifies the user code and its authority with the
panel. The 7073/A and 7173 activate the on-board Form C relay releasing a door strike or magnetic lock. To provide
added flexibility, the keypad allows connection of an external Wiegand output compatible reader.
Proximity Credential Compatibility
DMP keypads with internal proximity readers are compatible with most standard 125kHz proximity credentials. An
external 13.56MHz proximity reader can be connected and will be compatible with 13.56MHz proximity credentials.
For a list of publicly supported card formats, see Public Card Formats.
Note: Some proximity credentials are not compatible with DMP proximity keypads. Test the intended
proximity credentials with the application before installation. DMP does not guarantee compatibility with
credentials not purchased from DMP.
Program a Credential
1. Access the User Menu by pressing CMD until MENU? NO YES displays. Choose YES, and present your proximity
credential to the reader or manually enter your user code at the keypad.
2. Press CMD until USER CODES? displays.
3. Press any select key. Choose ADD.
4. At ENTER CODE: -, present the credential to the reader. The keypad works by reading the user code from the
data string sent by the access control reader.
