PROGRAM THE KEYPAD
Refer to the appropriate panel programming guide as needed. Operation for some programming options is restricted
to the appropriate model. To access the Keypad Options menu:
Hold down the back arrow and CMD keys for two seconds. At SET BRIGHTNESS, enter 3577 (INST) and press CMD.
The display changes to KPD OPT KPD DIAG and STOP.
Keypad Options
To program keypad options, press the select key under KPD OPT. When finished
programming, press STOP to save all programming.
Current Keypad Address
Set the current keypad address from 01 to 08 for XT30/XT50 or XR150 Series panels,
or 01 to 16 for XR550Series panels. The default address is 01. To change the current
address, press any select key and enter the new address and press CMD. Do not enter
a leading zero for addresses 01 to 09.
Keypad Mode
Keypads with programmed zones must be supervised and cannot share an address
with other keypads. Unsupervised keypads can operate together sharing the same
address, but cannot be used when Device Fail Output has a programmed value other
than zero. To select a keypad mode, press the select key under SUP or UNSUP. An
asterisk appears next to the selected option.
Default Keypad Message
Enter a custom message of up to 16characters to appear at the top of the keypad
display. Press any select key, enter a new message, and press CMD.
Arm Panic Keys
Use this option to enable or disable the panic keys. Press the select key under the
desired name: PN (panic), EM (emergency), and FI (fire). Press the select key again to
disable the panic option. Once the panic option is enabled, an asterisk displays next
to the selected option(s).
7/0 Panic
Press the fourth select key to choose YES, configuring the 7and 0 keys as two-button
panic keys. Select NO to disable the option. Default is NO.
Activate Zone 2 Bypass (7073/A, 7173 only)
Select YES to activate the zone 2 bypass operation. Selecting NO allows standard
zone operation on zone 2. The default is NO.
If the door being released by the keypad is protected (contact installed), a
programmable bypass entry/exit timer can be provided by connecting its contact
wiring to the keypad zone 2. When the onboard Form C relay activates and the user
opens the door connected to zone 2, the zone is delayed for the number of seconds
programmed in ZONE 2 BYPASS time allowing the user to enter/exit during an armed
period.
KPD KPD
OPT DIAG STOP
CURRENT KEYPAD
ADDRESS: 1
KEYPAD MODE:
*SUP UNSUP
DEFAULT KPD MSG:
ARM PANIC KEYS:
*PN EM *FI
7/0 PANIC
ENABLE: NO
ACTIVATE ZONE 2
BYPASS? NO
