7000 Series Installation and Programming Guide | Digital Monitoring Products 14
No Communication with Panel
Define the relay action when communication with the panel has not occurred for
5seconds: OFF, SITE, ANY, ON, or LAST. Default is OFF. Press any select key or area
to change the default relay action:
Press the first select key or area to choose OFF (Relay Always O). The relay does
not turn on when any Wiegand string is received. OFF does not aect any REX
operation. If communication is lost during a door strike, the relay remains on for the
door strike duration but turns o at the end of the door strike timer.
Press the second select key or area to choose SITE (Accept Site Code). Door access
is granted when the Wiegand site code string received matches any programmed site
code. Refer to Require Site Code for more information.
Press the third select key or area to choose ANY (Any Wiegand Read). Access is
granted when any Wiegand string is received.
Press the fourth select key or area to choose ON (Relay Always On). The relay is
always on.
Press CMD to display additional actions. Press the first select key or area to choose
LAST (Keep Last State). The relay remains in the same state and does not change
when communication is lost.
Keypad Language
Define the keypad’s language. Default is ENGLSH.
Press any select key to change the language options.
Press select key 1 to select English. Press select key 2 to select Spanish. Press select
key 3 to select French. Press select key 4 to select Dutch.
Press CMD to advance the language options.
Press select key 1 to select Greek. Press select key 2 to select Czech.
NO COMM WITH PNL
OFF SITE ANY ON
NO COMM WITH PNL
LAST
KYPD LANGUAGE:
LANG: ENGLSH
KYPD LANGUAGE:
ENG SPN FRN DUT
KYPD LANGUAGE:
EΛΛ CZK
