DMP Electronics Thinline Series Installation And Programming Guide

7000 Series Installation and Programming Guide | Digital Monitoring Products 13
Site Code Position and Length
Enter the site code start position and length in the data string. Press select key 2 to
clear the site code start position and enter a number between 0-255. Press CMD to
save. Default is 1.
Press select key 4 to clear the site code length and enter a number between 1-24.
Press CMD to save. Default is 8.
User Code Position and Length
Define the user code start bit position and length. Press select key 2 to clear the user
code position and enter a number between 0-255. Press CMD to save. Default is 9.
Press select key 4 to clear the user code length and enter a number between 16-64.
Press CMD to save. The default is the DMP value of 16.
Require Site Code
Press the top row select key or area under YES to use a site code and press CMD to
view the site code entry display. Press NO to advance to NO OF USER CODE DIGITS.
Default is NO.
In addition to user code verification, door access is only granted when any one site
code programmed at the SITE CODE ENTRY option matches the site code received in
the Wiegand string.
Site Code Display
You can program up to eight 8-digit site codes. The site code range is 0-16,777,214.
In the keypad display, enter site code 1 and press CMD. The display will ask for site
code 2 followed by site code 3 and so on. When you have selected the site code you
want to change, press CMD.
Number of User Code Digits
The keypad recognizes user codes from 4-12digits long. Press any top row select
key or area to enter a user code digit length. This number must match the user code
number length being programmed in the panel. The device will recommend a number
of user code digits based on the user code length. Default is 5.
All bits are read and converted into a decimal number string. The number string is left
padded with 0 (zero) if needed for long user code lengths.
Example: # decoded 1234567
10 digits 0001234567
4 digits 4567
SITE CODE
POS: 1 LEN: 8
USER CODE
POS: 9 LEN: 16
REQUIRE SITE
CODE: NO YES
SITE CODE 1:
NO OF USER CODE
DIGITS: 5

DMP Electronics Thinline Series Specifications

General

Brand	DMP Electronics
Model	Thinline Series
Category	Keypad
Language	English
