5.3 Exchange of Fuse
1 . Disconnect the main power cable before
opening the cover, otherwise you might risk an
electric shock.
2. To exchange the fuse, please remove the
cover first.
Replace the cover properly after exchanging the
fuse.
A For continued protection against risk of fire, replace only with
same type and rating of fuse.
5.4 How to Adjust the Feeding Gap
The adjusting screw of the feeding gap on the top cover has already
been set at the factory. You may need to adjust the feeding gap if the
following problems occur during counting/sorting.
• Frequent jams, or banknote pass the feeder with difficulty-tum the
adjusting screw clockwise to make the gap larger.
• Frequent "double notes" or "chained notes" error message-tum the
adjusting screw counter-clockwise to make the clearance smaller.
Note: The adjusting screw is very sensitive, make only minor
adjustment.
