6.3 Recommendations for motion control
If several lifting devices with hanging load are equipped with remote controls and work near to
each other (e.g. in a production hall) each remote control must be clearly marked to indicate
which load is controlled by which remote control.
For this purpose coloured arrows can be used to mark the equipment and the corresponding
pushbutton on the remote control.
The movement direction of the control buttons should correspond to the movements of the
lifting equipment with hanging load. The symbols must be placed in a way that a clear relation
between the position of the control switches on the operator panel and the direction of movement
is there.
