2.10.1 Function diagrams
Rotational switches B=0:
-Protective devices on inputs S11-S14 and S21-S24 always active,
manual start only via start button on S42
- Remote control is active, when one control contact on S32 or S 34 is open.
-Reset of remote e-stop with remote start button (+infra red)
-t
max.
Adjustable monitoring time with rotational switch A
2.10.1 Funktionsdiagramme
Rotational switches B=0:
-Protective devices on inputs S11-S14 and S21-S24 always active,
manual start only via start button on S42
- Remote control is active, when one control contact on S32 or S 34 is open.
-Reset of remote e-stop with remote start button (+infra red)
-t
max.
Adjustable monitoring time with rotational switch A
