2.10.1 Function diagrams
M9586
22 1 1
t<
3s
t<
1s
t<t
max
auxiliary supply
(A1/A2)
control contact 1
(S32)
control contact 2
(S34)
remote E-stop
LED "reception"
output 58,
LED "run 2"
(failure code)
output 48
(failure)
LED "run1"
E-stop or LC 1
S12-S14
E-stop or LC 2
S22-S24
start button S42
remote start button
relays and LEDs
K1-K2
outputs 27 to 77
output 17
(enabeld without
radio control)
: off : continuous : slow symmetric flashing : fast flashing : flashing code
remote control
must be de-activated
