DOLD GMBH Operating instructions DMP 96 A
DMP 96 A Version: 020 Number of pages: 26
H0e020bA4.doc Edition: 07.11.2006
13
Display: Meaning:
"noP" Relay contact K 2 deactivated
"tun" Enter self-optimization level
"HLP" Correcting setpoint
"OPt" Self-optimization activated
"inF" Enter information level
"SEn" Sensor ID
"Er.1" Sensor error message
"Er.9" System error message
7. Operation:
The operating structure of the DMP 96 A controller includes six separate levels:
Setting the setpoint (depending on configuration):
• via the operator level.
• via the setpoint entry level (by entering a code).
• the configuration level, where line compensation, range limits, control functions, switching
functions of the limit-value contact, and error allocations are defined.
• the parameterization level, which contains all parameters for adjusting the controller to the
control loop.
• the self-optimization level for setting the correcting setpoint and for starting or aborting
self-optimization.
• the information level for querying current program number and sensor ID.
7.1 Setting parameters on the various levels:
current value: +1
after approx. 3 s: +10
after approx. 6 s: +100
current value: -1
after approx. 3 s: -10
after approx. 6 s: -100
P
display value is accepted
The program returns to normal operating mode after the last parameter has been confirmed.
If no key is pressed within 20 seconds, the program automatically returns to normal operating
mode without accepting any value that has been changed.
After confirming an incorrect code number: Do not press any key for approx. 20 seconds.
Wait for program to return to normal operating
mode.
Enter new code.
