7.4.1 Switching response of the K 2 limit-value contact:
Switching function relative to rising actual value
Absolute limit value
b) Hysteresis "HY.2"
Setpoint value "LA.2"
a) Make contact (01)
b) Break contact (04)
Actual value X
a) Hysteresis "HY.2"
Limit value changing with setpoint value
b) Hysteresis fix "HY.2"
Spreading ("SP.X" + "Lr.2")
a) Make contact (02)
b) Break contact (05)
Actual value X
a) Hysteresis fix "HY.2"
Setpoint value "SP.X"
Limit comparator closed in commodity load area
Setpoint value "SP.X"
Coding (03)
actual value X
Hysteresis 0.5 K
Symmetrical spreading "bd.2"
Symmetrical spreading "bd.2"
Hysteresis 0.5 K
Limit comparator closed in commodity load area
Setpount value "SP.X"
Actual value X
Hysteresis 0.5 K
Symmetrical spreading "bd.2"
Symmetrical Spreading "bd.2"
Hysteresis 0.5 K
Coding
(06)
Figure 5: Switching response of the K 2 limit-value contact
7.5 The parameterization level:
Setting control parameters:
P
Press for approx. 3 s to get display: " Cod "
100
Enter code: 55
P
Confirm code: Display: " PAr "
