Starting and aborting optimization:
Optimization can be started or aborted on the self-optimization level (only when function is re-
leased).
Optimization optimizes for heating or cooling (heating controller or cooling controller, depending
on configuration).
P
Press for approx. 3 s to get display: " Cod "
100
Enter code: 111
P
Confirm code: Display: " tun "
P
Jump to self-optimization level.
Display: Parameter: Range: Factory
setting:
"HLP" Correcting setpoint (see formula)
70...100 % for heating
100...130 % for cooling
70...130 % 90 %
"Opt"
"on"
Start self-optimization
P
Confirm
"OFF"
"Opt"
"OFF"
Abort self-optimization
P
Confirm
For optimization the algorithm uses a correcting setpoint which is spread by the value set for the
setpoint (parameter "HLP").
This correcting setpoint prevents temperature peaks occurring above the setpoint during optimi-
zation from damaging the controlled commodity. The optimization difference must be adjusted to
the specific application.
Corr. setpoint ( °C) =
Setpoint (
°
C)
⋅
Parameter " HLP" (%)
100 (%)
During the optimization process the controller works with a P-regulating characteristic curve
(Pb = 0,1%). Setpoint (correcting setpoint) / "OPt" are appear alternately on the display as a vis-
ual check.
To calculate parameters the controller requires two oscillations, after which it brings the control
variable in line with the setpoint.
