Dolmar PC-7614V - Component Identification; Power Cutter Parts Diagram

12
Denomination of components
1. Rear handle
2. Filter cover
3. Lock screw
4. Top cover for air lter and spark plug cap
5. Top cover
6. Front handle
7. Protection hood
8. Tensioning screw
9. Hex. nut
10. Mufer
11. Starter grip
12. Oil tank cap
13. Fuel tank cap
14. Fuel pump (Primmer)
15. Cutting disc
16. Outer ange
17. Hex bolt
18. Switch
19. Safety locking button
20. Throttle lever
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
20
6
