Dolmar PC-7614V - Starter Motor Cleaning; Starter and Clutch Cleaning

21
Cleaning the starter
When the starter doesn’t work well, for example the starter rope
doesn’t return to initial position, it is necessary to blow off dust
from the starter (14) and the clutch (15).
To clean the starter and the clutch, remove three screws (16) for
access.
15
16
14
