Setting Battery 2
If you have a second battery bank connected, the controller will
immediately prompt you to set the battery type for Battery 2
with a blinking number 2.
If there is not a second battery bank connected to the controller, or if the second battery bank is connected with reverse
polarity, the controller will not prompt you to select battery type for Battery 2, and no status information will be displayed
on the LCD screen.
To select the charging prole of battery bank 2, press the B
Button to toggle through the prole options: Sealed/Gel, AGM,
Flooded, or LFP.
To conrm the battery prole, press and hold the A Button for
3 seconds.
Non-volatile memory: Any settings made on the GP-PWM-30-
UL will be saved even when the power has been disconnected
from the controller.
8.3 BATTERY CHARGING PROFILE CHART
OPERATING INSTRUCTIONS
