BATTERY STATE OF CHARGE
SYMBOLS BATTERY VOLTAGE
Shows only after full Boost or Equalization Cycle
>= 12.6V
>= 11.8 -12.6V
> 11.0 -11.8V
<= 11.0V
100% Shows only after full Boost or Equalization Cycle
< 12.8V and > 11.0V
0% <= 11.0V
10. INVERTER CONTROL ON/OFF
The following Go Power!® inverters can be turned on/off through the GP-PWM-30-UL when a modular 6p4c RJ11 type connector is
used (included with an optional Go Power!
®
inverter remote):
- GP-ISW700-12 - GP-ISW1500-12
- GP-ISW1000-12 - GP-ISW2000-12
- GP-ISW1500-TS
*The GP-SW1500 Inverter is not compatible.
Note
DISPLAY SYMBOLS
