Technical description MCA1215 – MCA2440

6.1 Device versions

The PerfectCharge MCA battery chargers are available in different versions.

Your MAC battery charger can be used to charge batteries up to a specified battery

capacity (see chapter “Technical data” on page 31):

• MCA1215: suitable for charging one supply battery and one starter battery

• MCA1225, MCA1235: suitable for charging up to two supply batteries and one

starter battery

• MCA1250, MCA1280: suitable for charging up to three supply batteries

• MCA2415: suitable for charging up to two supply batteries

• MCA2425, MCA2440: suitable for charging up to three supply batteries

For the identification of your device, see the reference number on the type plate.

6.2 Connections and controls

NOTE

The version for continental Europe is depicted.

No. in

fig. 1, page 3

Explanation/function

1 Mains connection

2 LIN2 bus connection

3 TENMP/LIN1 bus connection

4 CN2 socket for Alarm and Fan

5 Status LED

6DIP switch

7 Battery terminals (+)

8 Battery terminals (–)

9 Starter battery connection

(MCA1215, MCA1225, MCA1235 only)

MCA1215-2440--IO-16s.book Seite 16 Freitag, 11. November 2016 9:15 21
