6.3 Battery charging function
The charging characteristics are referred to as modified IU0U characteristics.
1: I phase (bulk)
At the beginning of the charging process, the flat battery is charged with a constant
current (100 % charge current) until the battery voltage reaches the charging volt-
age. The charging current decreases when the battery has reached this charging
level.
No. in
fig. 2, page 4
Explanation/function
1 On/Off switch
2Fan
U0 U
U
I
I
1
100 %
6 %
234 65
t
U/V
I/A
