7.4 Navigation Tree

This section shows the menu ﬂow for the Passport

controls.

OPERATING MODES

Cool Mode

Heat Mode

Dehumidiﬁcation Mode

Automatic Mode

FAN MODES

Fan Mode

Manual Fan Mode

Fan-Only Mode

Cycled/Continuous Fan Mode

FAULT CODES

ASF Inside Sensor Failure

FIL Clean/Replace Filter

HPF High Pressure Fault

LAC Low AC Voltage

LPF Low Pressure Fault

PLF Pump Sentry Fault

FAULT HELP

Air Sensor Fault

Air Filter Fault

High Pressure Fault

Low Pressure Fault

Low AC Fault

Low Pump Flow Fault

DX PROGRAMMABLE PARAMETERS

P-1 Operating Mode

P-2 High Fan Limit

P-3 Low Fan Limit

P-4 Compressor Staging Time Delay

P-5 Inside Air Temperature Sensor Calibration

P-6 Failsafe Level

P-7 Low AC Voltage Shutdown

P-8 De-icing Cycle

P-9 Optional Pump Sentry

P-10 Display Brightness Control

P-11 Fahrenheit or Celsius Selection

P-12 Cycle Pump with Compressor

P-13 Reverse Automatic Fan Speeds During Heating

P-14 Cycle Fan With Compressor

P-15 Reverse-Cycle or Electric

P-16 Fan Motor Selection

P-17 Reset Memorized Defaults

P-18 Reserved

P-19 Reserved

P-20 Air Filter Cleaning/Replacement Timer Setting

P-21 Filter Cleaning/Replacement Timer Value & Reset

P-22 Voltage Calibration

P-23 Auto Mode Heat Diﬀerential

CW PROGRAMMABLE PARAMETERS

P-1 Operating Mode

P-2 High Fan Limit

P-3 Low Fan Limit

P-4 Reserved

P-5 Inside Air Temperature Sensor Calibration

P-6 Reserved

P-7 Reserved

P-8 Reserved

P-9 Reserved

P-10 Display Brightness Control

P-11 Fahrenheit or Celsius Selection

P-12 Reserved

P-13 Reverse Automatic Fan Speeds During Heating

P-14 Cycle Fan With Compressor

P-15 Reverse-Cycle or Electric

P-16 Fan Motor Selection

P-17 Reset Memorized Defaults

P-18 Hydronic Water Valve Forced Open

P-19 Water Temperature Diﬀerential

P-20 Air Filter Cleaning/Replacement Timer Setting

P-21 Filter Cleaning/Replacement Timer Value & Reset

P-22 Voltage Calibration

P-23 Auto Mode Heat Diﬀerential

DISPLAY INDICATORS

Fan Fan Modes

Up+Down Operating Modes

Fan+Power Service History Log

Power Programming Menu

(DX) Down+Power Compressor

Hour Meter
