Specifications Passport I/O Digital Controls
4.3 Available System Inputs
Input DX CW
Ambient or Inside Air Temperature
Sensor
x x
High Refrigerant Pressure x
Water Inlet Temperature Sensor x
Optional
Alternate Air Temperature Sensor x x
Outside Air Temperature (OAT)
Sensor
x x
Low Refrigerant Pressure x
Pump Sentry Water Sensor x
4.4 Operational Specifications
Set Point Operating Range
65°F to 85°F (18°C to
29°C)
Ambient Temperature
Operating Range
Displayed
5°F to 150°F (-15°C to
66°C)
Sensor Accuracy
± 2°F @ 77°F (±1°C @
25°C)
Low Voltage Limit
100–120 VAC
75 VAC
Low Voltage Limit
208–240 VAC
175 VAC
Low Voltage Processor
Reset
50 VAC
Universal Line Voltage 100–240 VAC
Frequency 50 Hz or 60 Hz
Fan Output
6 A @ 100–120 VAC
6 A @ 208–240 VAC
Valve Output
5 A @ 100–120/
208–240 VAC
For DX Only:
Passport I/O circuit
boards revision F and
newer; and, U-boards:
Heater Output (using
valve relay)
15 A @ 100–120 VAC
10 A @ 208–240 VAC
For DX Only:
Passport I/O circuit
boards revision E and
older: Heater Output
(using heater relay)
30 A @ 100–120 VAC
20 A @ 208–240 VAC
For CW Only:
Heater Output
(using compressor relay)
30 A @ 100–120 VAC
20 A @ 208–240 VAC
Pump Output
1/4 HP @ 100–120 VAC
1/2 HP @ 208–240 VAC
For DX Only:
Compressor Output
1 HP @ 100–120 VAC
2 HP @ 208–240 VAC
Minimum Operating
Temperature
0°F (-18°C)
Maximum Ambient
Operating Temperature
180°F (82°C)
Maximum Rh Conditions 99% Non-condensing
Power Consumption < 5 W
