VARC Chiller Controls General Information
Parameter VARCX48 VARCX60 VARCX72 VARCX120 Data Type
Factory Settings
Control Temp Mode CCW Supply CCW Supply CCW Supply CCW Supply
Number of Stages 1 1 1 1
Electric Heat No No No No
Power Cycle Retain Mode Retain Mode Retain Mode Retain Mode
Logo Dometic BLK Dometic BLK Dometic BLK Dometic BLK
Background Ocean Ocean Ocean Ocean
Flow Switch Yes Yes Yes Yes
High Pressure Switch Yes Yes Yes Yes
Low Pressure Switch No No No No
EH Flow Switch No No No No
Load Shedding Yes Yes Yes Yes
SW Temp Inlet Yes Yes Yes Yes
Sea Water Pump Settings
Control By Demand By Demand By Demand By Demand
Off Delay 5 5 5 5 Seconds
Pump Current No No No No
Current Selection 10 10 10 10 Amps
Pump Control Master Master Master Master
Chilled Water Pump Settings
Control Continuous Continuous Continuous Continuous
Flow Prove Delay 10 10 10 10 Seconds
Off Delay 5 5 5 5 Seconds
Pump Current No No No No
Current Selection 10 10 10 10 Amps
Reversing Valve
RV Delay On Time 45 45 45 45 Seconds
Electric Heat
Stage Up Delay 60 60 60 60 Seconds
Stage Down Delay 20 20 20 20 Seconds
Compressor
Min On Time 60 60 60 60 Seconds
Min Off Time 10 10 10 10 Seconds
Min Time between Starts 60 60 60 60 Seconds
Load Up Time 10 10 10 10 Seconds
Force Rotation 12 12 12 12 Hours
Load Up Stg Delay 60 60 60 60 Seconds
Avg Supply Delay 240 240 240 240 Seconds
