MODES OF OPERATION Smart Touch Cabin Control Installation & Operations Manual
18 L-3380 ENGLISH
PROGRAM SCHEDULER
Program Scheduler lets you start and/or stop the A/C unit at specific time, day of the week, mode and temperature set point. To
access the Program Scheduler, go to Main Menu, Program Scheduler, and select the setting to modify.
Figure 25: Smart Touch Program
Scheduler Pages 1 and 2 of 4
1. Scheduler mode As soon as the Program Scheduler is enabled, it will
immediately start applying the programs as defined in the various day
settings.
2. Program: Mon-Fri
3. Program: Sat-Sun
4. Program: Day of the Week (Seven different programs)
Each program has a mode, time, cooling set point, and heating set point (if dual set
points are enabled). The Mode choices are Off, Cool, Heat, Auto, Dehumidify. If Dual
Set Points is selected, the cooling set point is settable for Cool and Auto, and the
heating set point is settable for Heat and Auto. Set points are not settable for Off or
Dehumidify.
Figure 26: Smart Touch
Program #1 Scheduler Page 1 of 4
DATE/TIME MENU
Date/Time Menu lets you set the display time, its format, and optional display on Main
Screen. To access the Date/Time Menu, go to Main Menu, and Date/Time Menu, and
select the setting to modify.
Figure 27: Smart Touch
Date and Time Settings
1. Date/Time Display Choose between On or Off to control the display of date/
time on Main Screen only.
2. Date/Time Format Choose between Automatic by Line Freq (60Hz line
frequency results in M/D/Y 12-hour format, and 50Hz line frequency results
in D/M/Y 24-hour format), M/D/Y 12-hour, or D/M/Y 24-hour.
3. Date/Time Settings This setting allows date and time modification. Each
date and time value are individually editable. The day of the week will
automatically be calculated based upon the date.
To Next Page
