Smart Touch Cabin Control Installation & Operations Manual MODES OF OPERATION
L-3380 ENGLISH 23
Figure 42: Smart Touch
Faults History
1. Faults History Lets you view the history of previously cleared faults and the
current active faults.
NOTE: To view the cleared faults, hold CLR button 10 seconds.
Figure 43: Smart Touch
Compressor Run Hours View
2. Compressor Run Hours Lets you see the current amount of hours the
compressor has run. The value can be cleared by pressing the CLR icon.
NOTE: To view the cleared faults, hold CLR button 10 seconds.
Figure 44: Smart Touch
Fan Run Hours View
3. Fan Run Hours Lets you see the current amount of hours the fan has run.
The value can be cleared by pressing the CLR icon.
NOTE: To view the cleared faults, hold CLR button 10 seconds.
When used with optional electric heat or Auxiliary heat, the fan remains on for 4
minutes after the heater cycles off even if fan is set to cycled operation.
QUICK-START OPERATIONS CHECKLIST
1. Ensure seawater-intake ball valve (seacock) is open.
2. Make sure the control is powered OFF.
3. Turn on the air conditioner circuit breaker. If the seawater pump has its own circuit breaker, turn that on also.
4. Turn the control ON.
5. Press the Fan icon. Verify that the fan is running and that there is steady airflow out of the supply-air grille.
6. Select a temperature set point lower than the current cabin temperature. This starts the compressor and seawater
pump.
7. Check for a steady solid stream of water from the overboard discharge.
8. Verify that there is steady airflow out of the supply-air grille.
If the unit does not appear to be operating properly, refer to the guidelines in “TROUBLESHOOTING” on page 32.
NOTICE
Do not turn the unit off and then immediately turn it back on. Allow at least 30 seconds for refrigerant
pressure to equalize.
