Domino D320i Red User Manual

TECHNICAL REFERENCE
4-6 L025317 Issue 5July 2014
CONTROLLER TYPES
Controller Type D320i D620i
Electrical Requirements:
Mains Power:
Voltage 90-264VAC 90-264VAC
Frequency 47Hz-63Hz 47Hz-63Hz
max. Power Consumption 1050VA 2000VA
Laser Power:
Voltage 30V DC 48V DC
max. Current 5 A 22 A
IP 43 Enclosure:
Dimensions
(L x W x H) [mm]
371x430x154 371x430x310
Cooling fan cooled fan cooled
Operating Temperature
5° to 40° C
(41° to 100°F)
5° to 40° C
(41° to 100°F)
Controller Type D320i IP D620i IP
IP 55 Enclosure:
Dimensions
(L x W x H) [mm]
400x541x229 400x541x458
Cooling fan cooled fan cooled
Operating Temperature
5° to 40° C
(41° to 100°F)
5° to 40° C
(41° to 100°F)
Environment Humidity
max. 90% RH, non
condensing
max. 90% RH,
non condensing

Domino D320i Red Specifications

General

Print Technology	Thermal Transfer
Operating Temperature Range	5°C to 40°C
Ribbon Width	4.33" (110mm)
Ribbon Length	300 m (984 ft)
Connectivity	USB, Ethernet, Serial
