Domino D320i Red User Manual

INSTALLATION INSTRUCTIONS
2-56 L025317 Issue 5 July 2014
Achieving Maximum Line Speed
The D-Series includes a feature to extend the marking field when a moving
product is marked as it moves past the print head. This feature is used to
achieve maximum line speed.
Marking mode has to be configured for “Mark on the Fly”.
Adjust the marking mode via: Home > Settings > Production Line Setup >
Line Movement > Setup Line Movement
Normally the first object in the direction of movement of a message is
marked when it has entered the marking area below the laser lens.
Product movement direction
Product
Marking field on product
Marking area
Example for Marking on the Fly without an extended field
