Domino D320i Red User Manual

INSTALLATION INSTRUCTIONS
L025317 Issue 5 July 2014 2-5
Scanner Fields and Distances
All values in millimetres.
All values may fluctuate up to 5%.
i-tech 10mm Scanner
Focal Length
Maximum
Field
Usable
Field
Working
Distance
80 +/- 32 +/- 29 70
100 +/- 38 +/- 34 90
120 +/- 47 +/- 42 108
150 +/- 56.5 +/- 51 138
200 +/- 75.5 +/- 68 187
250 +/- 99.5 +/- 90 243
i-tech 15mm Scanner
Focal Length
Maximum
Field
Usable
Field
Working
Distance
250 270 x 260 200 x 254 246
325 360 x 344 262 x 334 326
450 485 x 467 356 x 452 427
