Step 5
Step 6
5. Insert rear filter inserter as shown with long arm
towards the front. Insert the right angle plate as
shown BETWEEN two filters. DO NOT insert the
angle bracket inside of a filter. Insert the rear angle
bracket in the space between the filter to the left of
the front angle bracket and the next filter to the left
so both angle brackets are straddling one filter.
6. Swing the long arm of the filter inserter from left
to right to open a space around the filter that the
inserter is straddling. Make sure the inserter is
pushed all the way to the back of the bags.
Step 7
Step 8
7. Install the front filter inserter with the long arm
towards the back as shown and the angle brackets
inserted into the spaces created by the rear filter
inserter.
8. Swing the long arm of the filter inserter from right
to left while keeping the inserter tight to the front of
the bags. This will create a space that will allow the
removal of the first bag.
