Cabinet Collector, Models 54-90
20
Hopper Attachments
5- or 55-Gallon Drum Packs with or without Slide
Gate
1. Apply 1/4-in diameter rope-type sealant to the drum
cover mounting plate flange.
2. Fasten the drum cover assembly to the hopper flange
using the hardware supplied.
Drum Cover Pack
with Gate Valve
Models 54-84 Shown
Drum Cover Pack
without Gate Valve
Pail Pack
without Gate Valve
Models 54-84 Shown
Pail Pack
with Gate Valve
Models 54-84 Shown
hopper flange
drum or pail cover
mounting plate
sealant
5- or 55-Gallon Drum Packs with and without Slide Gate
