Cabinet Collector, Models 54-90
14
Step 10
10. Remove the filter inserters and the rest of the filters.
1. Install the bags into the collector. All but the last bag
should be able to be installed easily.
2. Slide the rear hold down bar beneath the set screws
at the back of the collector.
3. To create space to install the last filter, install the
rear filter inserter so the right and left angle brackets
straddle one filter. Position the filter inserter so the
long arm of the inserter is towards the front.
Filter Installation - Model 90
Steps 1-2
Step 3
Step 9
9. Remove the filter that is between the filter inserts.
To Next Page
