Cabinet Collector, Models 54-90
16
8. Install the front hold down bar.
9. Tighten both front and rear hold down bar set
screws.
10. To make sure all bags are sealed properly, shine a
light up between each set of filters. If no light can be
seen from the top side, the bags are properly sealed.
If light can be seen, insert the filter inserter inside
the bag with the bent frame to expand the inside
width of the bag. In addition, it may be necessary to
install a bag clip (refer to the replacement parts list)
at the location of the leak and adjacent bag.
Steps 8
Step 9
Step 10
Dust Disposal
1. Turn collector OFF and empty dust container as
necessary to minimize dust in the hopper.
2. If the optional 5- or 55-gallon drum attachment is
used, empty when drum is 2/3 full.
3. If optional slide gate is used, close gate before
servicing drum.
4. Reinstall drum and open gate.
