A Series Diesel Engine Electrical System 146
Electric Fuel Shut Off Valve -
Replacement
8mm
Remove the electrical wire(s) and complete the
following steps.
24mm
Caution : When removing the valve, be careful not to
drop the piston and spring.
Clean around the valve.
Replace the valve and connect the electrical wire.
Oil Pressure Switch – Replacement
Disconnect the wire from the sending unit.
Note : The sending units illustrated may differ from
those installed by the equipment manufacturer.
Reconnect the wire to the sending unit.
Torque Value :
(Installed into Cast Iron)
16Nm [12 ft-lbs]
