A Series Diesel Engine Base Engine Components 183
Note : Mark the cylinder block so you can align the oil
hole in the cylinder block with the oil hole in the
bushing.
Install the bushing so that it is even with the front face
of the cylinder block.
Measure the installed bushing.
Inside Diameter:
Standard: 45.03 to 45.06 mm [1.773 to 1.774 in]
Tappet Inspection
Inspect the socket, stem and face for excessive wear,
cracks and other damage.
Limit
(A)
(B) and (C)
- Normal wear
- Abnormal wear – Do not reuse
