A Series Diesel Engine Base Engine Components 188
Warning : Wear protective glove when you install the
heated gear.
Install the gear. The gear must be installed so the
bevel on the teeth is toward the crankshaft side of the
flywheel.
Flywheel – Installation
Caution : Never use the timing pin to hold the crank-
shaft.
Use two capscrews in the front of the crankshaft, or
similar device, to hold the crankshaft when the
flywheel capscrews are being tightened.
17mm Socket, Torque Wrench
Tighten the capscrews in the sequence shown.
Torque Value: 85Nm [64 ft-lbs]
