A Series Diesel Engine Base Engine Components 168
Base Engine Components
Specifications
Valve Train
Valve Clearance
z - Intake 0.3mm [0.012 in]
z - Exhaust 0.3mm [0.012 in]
z Valve Guide Diameter
8.025 mm [0.316 in] MAX
8.010 mm [0.3153 in] MIN
z Valve Stem Diameter
7.97 mm [0.3138 in] MAX
7.96 mm [0.3134 in] MIN
z Valve Seat Angle
Intake 30 degrees
Exhaust 45 degrees
z Valve Depth (Installed)
0.6 to 0.8 mm [0.0236 to 0.0315 in]
Wear Limit: 1.0 mm [0.0394 in]
