A Series Diesel Engine Base Engine Components 174
Rocker Levers – Disassembly
If the rocker lever and push rods are to be inspected
for reuse, follow these steps.
Remove the retaining rings and thrust washers.
Remove the rocker levers.
Caution : Do not disassemble the rocker lever shaft
and pedestal. The pedestal and shaft must
be replaced as an assembly.
Remove the lock nut and adjusting screw.
