A Series Diesel Engine Base Engine Components 176
Inspect the pedestal and shaft.
Measure the shaft diameter.
Standard: 19.0 to 19.021 mm
[0.748 to 0.749 in]
Worn Limit: 19.09 mm [0.751 in]
Rocker Levers – Assembly
Install the adjusting screw and lock nut.
Lubricate the shaft with engine oil.
