A Series Diesel Engine Base Engine Components 195
Inspect all caps and main bearing crankshaft journals.
(refer to page 171)
Determine the size of the bearing removed and obtain
the same size for installation.
Refer to page 171 for the dimensions of the standard
and undersize main bearing journals.
Caution : Do not lubricate the side that is against the
cylinder block.
Apply a coat of Lubriplate 105 to the new upper
bearings.
Use the pin to push the bearing shell into position. Use
the pin to push against the end of the bearing with the
tang. Push the bearing in slowly being sure it is
aligned with the block. Make sure the tang on the
bearing sets into the notch.
Note : Make sure the tang on the bearing sets into the
notch in the bearing saddle.
