A Series Diesel Engine Base Engine Components 208
Install the push rods and rocker levers (refer to page
179).
Lubricate the cylinder head capscrews. Use the
illustrated torque sequence.
17mm
Torque Value:
Step 1 – 29 Nm [22 ft-lbs]
Step 2 – 59 Nm [44 ft-lbs]
Step 3 – 93 Nm [70 ft-lbs]
19mm
Caution: Be sure to lubricate the push rod sockets with
clean engine oil.
Install the rocker lever pedestal capscrews.
Torque Value: 59 Nm [44 ft-lbs]
Adjust the valve clearance (refer to page 179).
