D439E Service Manual 3. Engine Electrical System (D439E)
138
CAUTION
Be careful not to damage the parts when
removing rear bracket.
5. Remove the pulley (1) using air tool and
disassemble the rotor (2) and the front bracket (3).
CAUTION
Be careful not to be injured from the rotor
rotation when removing the pulley.
6. Remove the stator (1) from the rear bracket.
To Next Page
