D439E Service Manual 2. Engine Mechanical System (D439E)
47
8. Install the front oil seal slinger (1).
9. Install the front timing gear case (1).
Tightening torque : 21.6 ~ 32.3 Nm
(2.2 ~ 3.3 kgf.m, 16 ~ 24 Ib-ft)
CAUTION
a. Apply the Loctite #5699 or equivalent on the
assembly surface of timing gear case (1), and
then assemble it within 3 minutes.
b. Do not start the engine within 1 hour after
installing the timing gear case.
10. Install the power steering pump (1).
11. Install the water pump pulley (1) and water pump
assembly (2).
