Maintenance Section
197
Lubricant Viscosities and Refill Capacities
Lubricant Viscosities
LUBRICANT VISCOSITIES
FOR AMBIENT (OUTSIDE) TEMPERATURES
Compartment
or System
Oil
Viscosities
°C °F
Min Max Min Max
Engine
Crankcase
(Diesel)
API CJ4,
ACEA E9
SAE 5W30 -30 +30 -22 86
SAE10W30 -20 +30 -4 86
SAE5W40 -30 +40 -22 104
SAE10W40 -20 +40 -4 104
SAE15W40 -15 +40 5 104
SAE15W50 -15 +50 5 122
SAE20W50 -10 +50 14 122
Engine
Crankcase
(LP) and Lift
Chains
API SJ
SAE 5W30 -30 +30 -22 +86
Auto Shift
Transmission
API GL4
UTTO
(API GL4)
-20 +50 -4 +122
Power Shift
Transmission
DEXRON III
DEXRON III -20 +50 -4 +122
Hydraulic and
Power Steering
System
ISO 6743/4 HM
ISO VG32 -20 +30 -4 +86
ISO VG46 -10 +40 +14 +104
ISO VG68 0 +50 +32 +122
Drive Axle
Housing
Disc Brake
(OCDB) API
GL4
UTTO
(API GL4)
-20 +50 -4 +122
The SAE grade number indicates the viscosity of oil.
A proper SAE grade number should be selected
according to ambient temperature.
Refill Capacities
Refill Capacities
(Approximate)
D5/6/7
TON
3speed
D8//9
TON
3speed
G5/6/7
TON
2speed
Compartment
or System
Liters
Engine
Crankcase
w/Filter
D34P
D34NAP
12.6 4.3
Cooling
System
D34P
D34NAP
12.7 19.0
w/Coolant
Reservoir
tank
Fuel Tank - Diesel 137 250 -
DEF /
Ad-Blue
Tank
D34P 15 30 -
Auto Shift
Trans
mission
ZF
3WG94
21 -
Power
Shift
Trans
mission
PT50 13 13
Hydraulic Power
Steering System
117
Proper
quantity
117
Proper
quantity
Drive Axle
Disc
Brake
14 14
NOTE: The refill volume varies by the residual oil
volume. Check the level gauge and refer to
the related instruction on the oil replacement.
NOTE: Dieseling may occur, causing damage to the
engine if oil is refilled excessively. Refill the
oil half way between MIN and MAX using the
dipstick.
