38
Scheduled runs do not occur when the module is in Test
Mode waiting for a start request.
Test Mode
Auto Mode
Scheduled runs operate ONLY if the module is in Auto
Mode with no Shutdown or Electrical Trip alarm
present.
If the module is in Stop/Reset Mode or Manual
Mode when a scheduled run begins, the engine is
not started. However, if the module is moved into Auto
Mode during a scheduled run, the engine is called
to start.
Depending upon configuration by the system designer,
an external input can be used to inhibit a scheduled
run.
If the engine is running OFF LOAD in Auto
Mode and a scheduled run configured to ‘On Load’
begins, the set is placed ON LOAD for the duration of
the Schedule.
